Wire In Silicone Insulation 22AWG, (0,34 мм², 1 m, red, UL3135)
id: 913270
Wire In Silicone Insulation 22AWG, (0,34 мм², 1 m, red, UL3135)
General information
Warranty
Price coming soon
General information
Flexible and heat-resistant wire, suitable for electrical work
Price coming soon
The wire in silicone insulationis an ideal solution for working in limited space due to its flexibility. The silicone insulation of the wire provides plasticity and withstands sudden temperature changes, making it the best choice for electrical tasks. It is suitable for a wide range of applications, including electrical engineering work and laboratory projects, as well as home appliance repair and maintenance of the power network at home and in the workplace.
Features
- Flexibility makes it easy to lay wires in hard-to-reach places.
- Usage at very high and low temperatures.
- Resistance to oxidation thanks to the base of tinned copper with an antioxidant coating.
- Waterproof and short circuit protection.
Technical Specifications
| Manufacturer | Minzan |
| Conductor material | tinned copper |
| Insulation material | silicone |
| Core thickness | 0.08 mm |
| Core number | 60 |
| Conductor cross-section | 0.34 mm² |
| Conductor diameter | 0.72 mm |
| Maximum resistance | 59.4 Ohm/km (at t = 20 °C) |
| Maximum current | 8 A |
| Maximum voltage | 600 V |
| Temperature range | -60 °C ~ +200 °C |
| Size | 22 AWG |
| Color | red |
Package Contents
- Silicone wire (red) — 1 meter
Wire in silicone insulation color:
- Red
Wire in silicone insulation length:
- 1 m
Wire in silicone insulation AWG GB wire gauge:
- 22 AWG GB
Wire in silicone insulation Cross-section:
- 0,34 мм²
