Super Phosphor Oscilloscope SIGLENT SDS5034X

SIGLENT SDS5034X is a 4-channel Super Phosphor Oscilloscope with a bandwidth of 350 MHz, a sample rate of 5 GSa/s, and a standard record length of 250 Mpts. The tool is equipped with a digital voltmeter.

Features

• New generation of SPO (Super Phosphor Oscilloscope) technology.
• 4 analog + 16 digital channels.
• 256-level intensity grading and color temperature display modes.
• Trigger types: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern, Qualified, Video (HDTV supported).
• Supports serial bus trigger and decoding; protocols: I2C, SPI, UART, CAN, LIN, CAN FD, FlexRay, I2S and MIL-STD-1553B.
• Low background noise, supports 0.5 mV/div to 10 V/div voltage scales.
• Segmented acquisition (sequence) mode, dividing the maximum record length into multiple segments (up to 100,000). Its replay and analysis.
• Search and navigation.
• 39 automatic measurement function.
• Supports statistics with histogram, gating measurement, math measurement, history measurement and ref measurement.
• Math measurement: FFT, addition, subtraction, multiplication, division, integration, differential, square root.
• High-Speed hardware-based Average, Eres (Enhanced Resolution).
• Mask Test function.
• Large 10,1 inch TTFT-LCD display with 1024 × 600 resolution.
• Touch screen supports multi-touch gestures.
• Supports external mouse and keyboard.
• 10 types of one-button shortcuts.
• Interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11, Telnet, Socket, Web), Pass/Fail, Trigger Out, 10 MHz In, 10 MHz Out, VGA output.
• Built-in web server supports remote control by the LAN port using a web browser.
• Supports SCPI remote control commands.

Technical Specifications

Video

You'll find even more video reviews in the Video tab. Go and check it out!

User Manual

Download SIGLENT SDS5034X User Manual.

Package Contents

• Super Phosphor Oscilloscope SIGLENT SDS5034X — 1 pc.
• USB cable — 1 pc.
• Passive probe — 4 pcs.
• Power cord — 1 pc.
• Certificate of calibration — 1 pc.
• User manual — 1 pc.

Digital oscilloscope screen size:

• 10.1" TFT display

Digital oscilloscope number of channels:

• 4-channel

Digital oscilloscope type:

• Desktop

• Mixed-signal

• With built-in generator

• Touch

• Phosphor

Digital oscilloscope sample rate:

• 5 GS/s

Digital oscilloscope bandwidth:

• 350 MHz

Digital oscilloscope storage capacity:

• 250 Mpts
