LCD Module Gluing Machine LY 898, (for LCDs up to 7", autoclave+vacuum)

Video

Technical Specifications

Operating Principles

Vacuum Platform

• Open the door, put in the display module, close the door.
• Turn the device on.
• Set the temperature of 40-60 °C. The temperature settings depend on the model of the display module.
• Press the Start button.
• When the vacuum stopped working, take the LCD module out.
• To release the pressure, press the button which is located next to the manometer under the cover.

Autoclave

• Make sure that there is no pressure in the chamber.
• Open the chamber door and put the display module in, close the door.
• Press the button, which is located next to the manometer.
• Close the door, press the Start button.
• When the process is finished, release the pressure. Press the button that is located next to the manometer under the cover.
• Now you can open the autoclave door.
• Warning! Do not open the device when it is working under pressure!
• The display and the glass are bonded. Now the LCD module can be installed in a cell phone.

Package Contents

• Device — 1 pc.
• Power cable — 1 pc.
• Filter for compressor — 1 pc.
• Rubber pad — 1 pc.
• Metal stand for pad — 1 pc.
• Metal shelf for LCD — 1 pc.
• Plywood box — 1 pc.

LCD Module Gluing Machine is compatible with the following models of Cell phones:

• Apple iPhone 5
• Apple iPhone 5S
• Samsung I9300 Galaxy S3
• Samsung I9305 Galaxy S3
• Samsung I9500 Galaxy S4
• Samsung I9505 Galaxy S4
• Samsung N7100 Note 2
• Samsung N7105 Note 2
• Apple iPhone 5C
• Apple iPhone 4
• Apple iPhone 4S
• Apple iPhone 6
• Apple iPhone 6 Plus
• Samsung N900 Note 3
• Samsung N9000 Note 3
• Samsung N9005 Note 3
• Samsung N9006 Note 3
• Samsung N910H Galaxy Note 4
• Apple iPhone SE

LCD module gluing machine characteristics:

• For LCDs up to 7"

• Autoclave+vacuum
