Hot Air Repairing System AOYUE 738

Features

• Microprocessor-controlled ESD safe unit.
• All digital display of hot air temperature, soldering iron temperature and air pressure with touch type panel controls.
• Three in one environment friendly repairing system that combines the functions of a Hot Air Gun, a Soldering Iron and a Smoke Absorber.
• Unique 15-minute stand-by auto sleep mode. Returns to previous setting when the handle is held up again.
• Designed with an auto-cool off process. Upon turning the unit off, it starts to blow cold air until it reaches a safe temperature of 85 degrees, this is to ensure safety and to prolong usage life of the heating element.
• Creative built-in smoke extractor that absorbs the fumes created at the source. Eliminates the space hindering smoke absorbing units yet allowing a healthy environment.
• Compatible with various type of air nozzles.
• Compatible with different kind of tips.

Technical specifications

Compatible Soldering Tips

Conical Soldering Tips
AOYUE T-0.5C	AOYUE T-0.8C	AOYUE T-B
AOYUE T-I	AOYUE T-LB	AOYUE T-S4
AOYUE T-S8	AOYUE T-SB	AOYUE T-SI
Bevel Type Soldering Tips
AOYUE T-1C	AOYUE T-1.5CF	AOYUE T-1.5CM
AOYUE T-2C	AOYUE T-2CF	AOYUE T-2CM
AOYUE T-3C	AOYUE T-3CF	AOYUE T-3CM
AOYUE T-4C	AOYUE T-4CF	AOYUE T-4CM
AOYUE T-S6	AOYUE T-S7
Chisel Type Soldering Tips
AOYUE T-0.8D	AOYUE T-1.2D	AOYUE T-1.2LD
AOYUE T-1.6D	AOYUE T-2LD	AOYUE T-2.4D
AOYUE T-3.2D	AOYUE T-3.2LD	AOYUE T-S3
AOYUE T-S9
Bent Type Soldering Tips
AOYUE T-0.2RB	AOYUE T-1.8H	AOYUE T-H
Knife Type Soldering Tips
AOYUE T-K
Soldering Tips for SMD
AOYUE T-R	AOYUE T-RT

Hot air soldering station pump type:

• Compressor

Hot air soldering station design type:

• Desktop

Hot air soldering station vacuum pick-up tool:

• Non-available

Hot air soldering station desoldering pump:

• Available

Hot air soldering station power supply:

• Non-available

Hot air soldering station soldering iron power:

• 45 W

Hot air soldering station hot air gun power:

• 500 W

Hot air soldering station desoldering gun:

• Non-available
