DC Power Supply SIGLENT SPD3303X-E

Siglent SPD3303X-E is a programmable high-precision linear DC power supply with 3 output channels and a 220 W max. output power.

Features

• 3 independent controlled and isolated outputs
  • 32 V / 3.2 A × 2
  • 2.5 V / 3.3 V / 5 V / 3.2 A × 1
• 4 digits voltage, 3 digits current display, minimum resolution: 10 mV / 10 mA
• 3 output modes: independent, series and parallel connect
• 4.3-inch TFT-LCD display with 480×272 resolution
• 100 V / 120 V / 220 V / 230 V compatible design
• Intelligent temperature-controlled fan
• Clear graphical interface, with the waveform display function
• Save/recall 5 group system specifications, supports data storage expansion

Technical Specifications

Package Contents

• Siglent SPD3303X-E power supply – 1 pc.
• Power cable – 1 pc.
• USB cable – 1 pc.
• Crocodile clips – 1 set
• Software CD and user manual – 1 set

Laboratory power supply type:

• Transformer

• Programmable

Laboratory power supply number of channels:

• Three-channel

Laboratory power supply Max. current:

• Up to 3 A

Laboratory power supply Max. voltage:

• Up to 32 V

Laboratory power supply indicator type:

• 4.3" color LCD display

Laboratory power supply maximum power:

• 220 W
